ALMAC JIBBI 1250 EVO
ALMAC JIBBI 1250 EVO

Jibbi 1250 LTH

Key Specs

  • Min. width: 1.15m
  • Capacity: 230 kg
  • Max height: 12.20 m

Key Feature

  • Equipped with innovative bi-leveling technology, able to facilitate the various work activities of your operators
  • Possibility to operate on rough terrain and / or on steep slopes
  • Excellent compactness, versatility, and ease of use
  • Removable basket
Compare
Categories: , Tags: , , , ,

Description

Basket capacity 230 kg
Max working height 12.2 m
Max height basket floor 10.2 m
Moving height 8.0 m
Max outreach (load 80 kg) 7.0 m
Max outreach (load 230 kg) 5.4 m
Rotation angle +/-110°
Basket size 1.4 x 0.7 m
Basket rotation angle +/-70°
Powered Lithium battery pack 300Ah-48V DC 4 kW
Longitudinal levelling +/- 15°
Lateral levelling +/- 15°
Max gradeability 25°
Max side gradeability 25°
Drive speed (fast) 2.0 km/h
Security speed 0.3 km/h
Length in stowed position (with detached basket) 3.7 (3.0) m
Min width in stowed position 1.15 m
Max working width 1.95 m
Min height in stowed position 1.99 m
Traffic load 3.89 kN/m2
Total weight 2910 kg




Standard specification:
  • New Dynamic Work Performance (DWP by Almac)
  • Undercarriage integrated by new Safe-lock System
  • Cable remote console by AUTEC
  • Lithium battery pack 300Ah-48V
  • 220° Slewing ring rotation
  • Basket rotation kit +/- 70°
  • Integrated Drive System (using a single joystick)
  • Ultrasonic Anticollision System
  • Mixed slope levelling
  • Automatic & Dynamic Levelling
  • Pro-Active Levelling
Options:
  • Non-marking tracks
  • Radio remote control
  • Arctic lubricant for cold climate
  • Winch kit 200 kg
