Safe and Powerful Performance
Crystal Batteries™ is a unique technology that overcomes conventional battery problems by having a nearly solid-state electrolyte. This allows the battery to be discharged deeper, cycle more often, have a longer lifetime, and withstand extreme temperatures.
When compared head-to-head, Crystal Batteries™ excel amongst competitors with notable performance increases over standard AGM batteries and even Lithium. There is no comparison for the quality, price, and lifetime of Crystal Batteries™.
Crystal Batteries™ are grouped into 4 families, where each family addresses a different market and application.
Electric Vehicle Applications
Golf carts, marine, e-propulsion drives, AGV’s (Automatic Guided Vehicles).
General Storage Applications
Marine, Industrial, Renewable Energy, Rail & Transport, Camper, Defense.
Front Terminal Applications
Datacenters & Telecom, Marine, Rail & Transport.
Large Storage Applications
Data centers & Telecom, Industrial, Renewable Energy, Rail & Transport.
CRYSTAL BATTERY™ SAFETY TEST
CRYSTAL BATTERY™ KNOWLEDGE
What is a Crystal Battery™?
Crystal Batteries™ consists of a number of unique special features, including a microporous super absorbent mat (SAM), thick plates cast from a high-purity lead calcium selenium alloy (which ensures an extended life), and a SiO₂-based electrolyte solution. During operation, the charge/discharge cycles cause the electrolyte to solidify and form a white crystalline powder. As a result, this process eventually leads to a safer, high-performance, and more environmentally friendly battery. Furthermore, Crystal Batteries™ can be used as a substitute for most battery technologies in the lead category, such as lead-acid, lead gel, and AGM.
Are Crystal Batteries™ safe?
Crystal Batteries™ hold less acid, no cadmium, no antimony. These batteries are designed to be up to 99% recyclable and are classified as non-hazardous goods for transport purposes. Additionally, Crystal Batteries™ are also extremely low-gassing and produce no dangerous gases, making them suitable for indoor use and in confined spaces.
Do Crystal Batteries™ charge faster than lead acid, lead gel, or AGM batteries?
Yes, Crystal Batteries™ can be charged up to 3C (In Boost for short periods) without any impact on their cycle life. This means they can be charged 2-3 times faster than other batteries. Standard charging requires 0.3C for GS, LS, FT range, and 0.2C for EV Range.
In what applications can I use Crystal Batteries™?
Crystal Batteries™ are being used in a wide range of applications, including, but not limited to, telecoms, UPS, petrochem/marine, defence, renewable energy, health care, manufacturing, transportation, and electric motion (wheelchairs, golf carts & trolleys), caravan & RV, Recreational 4WD, LED Lighting, robotics, and more.
What size Crystal Battery™ do I need for my application?
Determine how many battery amps your application needs and how long it is needed for. Multiply both values to calculate the necessary ampere-hours (Ah). Add a 20% safety margin and select a battery from our product range overview. Parallel batteries deliver greater electric currents, and series-connected batteries deliver a higher voltage. In both cases, the storage capacity (Wh = watt-hours) increased by the amount of force each additional battery has.
Contact Mayon Machinery to let us know how we can assist you with Crystal Battery. With over 10 years of experience in the Philippines market, we are confident in delivering reliable products and excellent after-sales service.
