SUMITOMO 8FB25PXIII

Key Specs

Key Features

Capable of handling substantial loads, ideal for a wide range of material handling tasks.
Environmentally friendly with zero emissions, making it suitable for indoor use and sensitive environments.
Reduces noise pollution, contributing to a more comfortable and productive work environment.
Designed for extended operating times and lower energy consumption, reducing operational costs.
Maneuverable in tight spaces, enhancing productivity in warehouses and crowded areas.
Offers precise and smooth operation, improving safety and efficiency.
Designed for operator comfort and reduced fatigue during long shifts.
Built with Sumitomo’s renowned quality for long-lasting performance and minimal downtime.
Electric forklifts generally require less maintenance compared to IC engine models.

Compare

Description

Load capacity/Rated load	2500 kg
Load center	500 mm
Lift height	3000 mm
Free lift	155 mm
Tilt of mast forward/backward	6⁰/10⁰
Overall width	1160 mm
Height, mast lowered	1995 mm
Height, mast extended	3970 mm
Overhead guard height	2120 mm
Overall length	3455 mm
Length to fork face	2385 mm
Fork dimensions (length/width/thickness)	1070/100/45 mm
Fork spread width (min/max)	250/1020 mm
Turning radius (outside)	2035 mm
Wheelbase	1515 mm
Ground clearance, with load, below mast	120 mm
Minimum right-angle aisle width (1100 x 1100 pallet)	2070 mm
Right-angle stacking aisle width (1100 x 1100 pallet)	3595 mm
Machine weight	4100 kg

Travel (Control type/Output)	FET inverter/8.3 kW
Hoist (Control type/Output)	FET inverter/9.6 kW
Steering (Control type/Output)	FET inverter/9.6 kW
Storage battery (Type/Voltage: 5hrs)	clad/48V/565Ah

Tyre size, front	7.00-12-12PR(I)
Tyre size, rear	18×7-8-10PR(l)
