Description
Load capacity/Rated load | 2500 kg |
Load center | 500 mm |
Lift height | 3000 mm |
Free lift | 125 mm |
Tilt of mast forward/backward | 70/100 |
Overall width | 1180 mm |
Turning radius (outside) | 2000 mm |
Overhead guard height | 2085 mm |
Length to fork face | 2325 mm |
Fork dimensions (length/width/thickness) | 1070/122/40 mm |
Overall length | 3395 mm |
Wheelbase | 1525 mm |
Machine weight (no load) (front/rear) | 1650/2260 kg |
Gross weight (with load) (front/rear) | 5680/730 kg |
Drawbar pull (max.) (full load/no load) | 10/8.9 kN |
Lift speed, with load | 340 mm / sec. |
Lift speed, no load | 600 mm / sec. |
Travel speed forward, with load | 14.0 kph |
Travel speed forward, no load | 16.0 kph |
Travel speed reverse, with load | 14.0 kph |
Travel speed reverse, no load | 16.0 kph |
Climbing performance, with load (%) | 16 |
Climbing performance, no load (%) | 20 |
Battery Voltage/Capacity (5-hour ratings) – Min. |
48V/565Ah |
Battery Voltage/Capacity (5-hour ratings) – Min. |
48V/725Ah |
Battery Weight (Min. Capacity Type) | 830 kg |
Electric Motors – Drive | 10.7 kW |
Electric Motors – Load handling/Power Steering | 12.2 kW |
Control Type | AC Inverter |
Wheel number | 4 |
Wheels driven | 2 |
Tyres, type | Pneumatic |
Tyre size, front | 21×8-9-14PR (I) |
Tyre size, rear | 21×8-9-14PR (I) |
Brakes, type (service) | Hydraulic |
