MRT-X 1440 Easy 400°

Key Specs

  • Lifting capacity: 4 000 kg
  • Lifting height: 13.8 m
  • Max reach: 11.5 m
  • Engine: Perkins – Stage 3A
  • Power: 74.5 kW
  • Standard Fork: 1200 L x 125 W x 50 T mm

Key Feature

The MRT-X 1440 Easy 400° rotating telehandler is particularly suited to construction work and certain industrial tasks. Compatible with a wide range of attachments and with a lifting height of 14 m, you can easily handle heavier, bulkier loads of up to 4 tonnes with precision. Based on your needs it can function as either a telehandler, crane or work platform.

The automatic attachment recognition system configures the most appropriate load chart for the current attachment, saving you time and bother. To ensure maximum comfort on a daily basis, the spacious driver’s cab comes equipped with two ergonomic joysticks, suspension seating, and full 400° visibility.

Compare

Description

 :
 :
Lifting height 13.8 m 45’4″
Lifting capacity 4000 kg 8800 lb
Max reach 11.5 m 37’11”
Drawbar pull 8600 dan 19333 lbf
Moving speed 32 kmh 19.8 mph

Length (up to the back of the fork) 5.35 m 17’8″
Total length (fork included) 6.55 m 21’6″
Wheelbase length 2.32 m 7’7″
Width 2.4 m 7’10”
Overall width (stabilizers lowered) 3.98 m 13’1″
Height 2.97 m 9’9″
Weight (unladen) 12490 kg 27536 lb
Turning radius 5.25 m 17’2″
Ground clearance 0.34 m 1’1″

 :

 :

 :


Energy Diesel
Engine brand Perkins
Engine type Stage 3A
Engine manufacturer type 1104D-44T
Power 101 ch 101 hp
Power 74.5 KW
Max. Torque @ Rotation 392 Nm @ tr/min
Number of cylinders 4
Total capacity 4400 cm3 268.5 in3
Injection Direct
Cooling Water
Voltage 12 V
Amperage 120 Ah
Transmission type Hydrostatic

Pressure 270 bars
Hydraulic oil tank volume 150 l 39.6 gal

Standard tyres Pneumatic
Number of wheels (front/rear) 2/2
Number of drive wheels (front/rear) 2/2
Number of steering wheels (front/rear) 2/2
Number of braking wheels (front/rear) 2/0
Tyre dimensions (front) 400/70 – 20 14 PR
Tyre dimensions (rear) 400/70 – 20 14 PR
Parking brake Automatic negative handbrake
Driving position noise levels 79.7 dB
Environmental noise levels 104 dB
Vibrations affecting hands/arms <2.5 m/s

Must-have attachments:

Extensible Platform

Expandable Platform

  • Maximum safety in people uplifting
  • Legally approved for 3 persons
  • Reinforced and galvanized structure
  • Overload sensor
  • Non-slip metal flooring

Aerial Jib 2

Aerial Jib 2

  • Maximum safety in people uplifting
  • Positive and negative work area, 340° boom rotation
  • Legally approved for 2 persons

Frame mounted hook

Frame Mounted Hook

  • Very compact attachment that preserves machine’s stability
  • Safety: homologated swivel self locking hook
  • Basic attachment for safe suspended load handling

Crane

Crane

  • 2 forward reach possible for more flexibility in performing daily works
  • Safety : homologated swivel self locking hook

Crane with winch

Extension Jib with Winch

  • Perfect for transporting and placing beams, frames
  • Design that improves the forward reach of the telehandler
  • Turn your telehandler into a crane
  • Safety: limit sensor up and down
  • Safety: homologated swivel self locking hook
