Description
Load capacity/Rated load | 2500 kg |
Load center | 500 mm |
Lift height | 3000 mm |
Free lift | 140 mm |
Tilt of mast forward/backward | 60/100 |
Overall width | 1165 mm |
Height, mast lowered | 1990 mm |
Height, mast extended | 4055 mm |
Overhead guard height | 2075 mm |
Overall length | 3630 mm |
Length to fork face | 2560 mm |
Fork dimensions (length/width/thickness) | 1070/100/45 mm |
Fork-carriage width | 1000 mm |
Turning radius (outside) | 2325 mm |
Wheelbase | 1650 mm |
Ground clearance, with load, below mast | 115 mm |
Ground clearance, centre of wheelbase | 165 mm |
Practical intersecting aisle width | 2240 mm |
Practical aisle for right-angle stacking | 4085 mm |
Machine weight | 3665 kg |
Drawbar pull (max.) (stationary on slope/at 1.6 km/h) – with load | 19700/17600 N |
Lift speed, with load | 0,64 m / sec. |
Lift speed, no load | 0,67 m / sec. |
Lowering speed, with load | 0,5 m / sec. |
Lowering speed, no load | 0,5 m / sec. |
Travel speed forward, with load | 19 kph |
Travel speed forward, no load | 19.5 kph |
Max. gradeability, (stationary on slope/at 1.6 km/h) – with load | 34.2/30.2 % |
Engine manufacturer/type | Mitsubishi S4S Tier 2 |
Rated power acc. to DIN70020 | 44 kW/ 2300 rpm |
Rated torque acc. to DIN70020 | 183 Nm/ 1800 rpm |
Displacement | 3331 cc |
Fuel tank capacity | 66 L |
Transmission type | ATM (Torque Converter) |
Transmission forward/backward | 1/1 |
Wheels, number front/rear (x = driven wheels) | 2/2 |
Tyres, type | Pneumatic |
Tyre size, front | 7.00-12-12PR |
Tyre size, rear | 6.00-9-10PR |
Tread width, front/rear | 960/980 mm |
Brake, type (service) | Hydraulic |
Brake, type (parking) | Hand operated |
Pressure relief for attachments | 18.1 Mpa |
