Spider lift Teupen LEO13GT
Spider lift Teupen LEO13GT

LEO13GT

Key Specs

  • Working Height:  12.75 m
  • Platform Capacity: 200 kg
  • Weight: 1 450 kg

Key Features

  • Compact design
  • Ideal traffic load
  • Intuitive control system
  • High-performance stabilizer system
  • Easy to transport
  • TEUPEN “Fuzzy”
  • Dual power source


Compare
Categories: , Tags: , ,

Description

Performance

Working height, max. 12,75 m
Side reach, max. 6,05 m
Up and over clearance, max. 4,60 m
Basket capacity, max. 200 kg
Length with/without basket 4,75 m / 4,00 m
Transport height x width, min. 1,99 m x 0,78 m
Gradeability, max. 14,4 ° / 25,5 %
Total weight 1450 kg
Tracks, adjustable –
Stabilisation system Automatic
Power source – standard 230 V electric motor + Diesel
Power source – optional 230V electric motor + Battery drive (AGM)

Benefits

Flexible all-around

This investment really pays off. Compact like a scissor, light like a trailer, versatile like a boom – You always have the right solution for quick and efficient applications. In its height segment, the design of the LEO13GT delivers outstanding performance.
Easy transport

The light and compact LEO13GT is ideally transported on a light trailer with a small van. Always mobile and quick at the jobsite.
The TEUPEN track drive

The track drive with non-marking rubber tracks provides easy, precise maneuvering and protects sensitive flooring – from the platform or walking alongside the detachable cable remote control.
Compact with quickly detachable aluminum platform

The platform with its innovative geometry and rounded-off edges provides more positioning options. It is easily detachable for passing narrow entrances of only 78 cm. It takes less than one minute to remove and fit!
Intuitive control system

All functions are controlled from one spot. The detachable, well-arranged control panel with color-coded options allows intuitive operation with only two joysticks and one switch.
Rigid boom design – maximum stability and rigidity whilst at height

A larger knuckle assembly, strong boom design with only one articulation, a wide slewing ring assembly, and the patented TEUPEN “Fuzzy” electro-proportional control logic provide unrivaled smooth, stable, and precise lift operation.
Serval power sources

The LEO13GT is equipped with two power sources: a Hatz diesel engine and a 230v electric motor being the perfect specification to work indoors and outdoors effectively. There is also the option of a battery pack for this model.


CHASSIS

  • Powerful track drive with hydraulic braking system
  • Precise maneuvering via sensitive, electro-hydraulic cable remote control
  • White, non-marking rubber tracks with specially arranged profile for optimal grip

STABILISATION

  • Electrohydraulic stabilisation with automatic levelling and ground pressure sensor system
  • Wear-resistant, anti-friction outrigger pads

BOOM SYSTEM

  • All functions available from the platform
  • Removable cable remote control
  • Robust, lockable control panel

POWER SOURCE

  • Electric motor (230V, 12,9A, 2,2kW)
  • Diesel engine Hatz 1B30 (5,4kW/7,2Hp)
  • Start-stop device for combustion engine in the platform

PRODUCTIVITY, SAFETY, QUALITY

  • Hydraulic emergency lowering via hand pump
  • Power socket in the platform (110V/16A)
  • Detachable platform, including attachment point for safety harnesses
  • Drive operation without platform possible
  • Protected, internal power track for platform control
  • Impact-resistant cover over control box and control panel
  • Hydraulic system filled with biodegradable hydraulic oil
  • High-quality paint in RAL 3020 (red)
  • Hydraulic cylinders in RAL 9006 (white aluminum)
  • Engine unit & component support in RAL 9006 (white aluminum)
  • Unlockable check valves located directly on hydraulic cylinders
  • Hydraulic system protected by pressure relief valves
  • Solid base frame with full-length forklift pockets
  • Hour meter
