Mayon's Solar Pile Driver
Mayon's Solar Pile Driver

Solar Pile Driver

  • Designed and built to drive metallic piles on the ground for the structure of photovoltaic panel fields.
  • Compact design. Ideal for jobsites with less space, or for multiple smaller jobs that require continual transportation of the machine.
  • Simple to operate and very user-friendly.
Compare

Description

Technical Parameters of Solar Pile Driver:

Manufacturer

Qingdao Wangbaoqiang Industry

Model Name

MZ398Y

Drilling Diameter (mm)

90-400

Drilling Depth (m)

20-100

Air Consumption (m³/min)

10-26

Air Pressure (Mpa)

0.7-1.6(Medium)

1.6-2.46(High)

Rod Diameter (mm)

76/89

Applicable rock hardness (F)

6-20

Drilling Diameter (Screw) (mm)

Maximum 400

Drilling Depth (m)

0-30

Mountable Screw Diameter (mm)

130-400

Impel Itinerary for One Thrust (mm)

2600

Crawler Frame Tilt (°)

120

Crawler Frame Swing (°) (Both Left and Right)

40

Boom Swing (°) (Both Left and Right)

45

Rotation Speed (r/min)

0-110

Climb Ability (°)

45

Engine Model

WEIFANG DIESEL

Rated Power (kW)

92

Overall Dimensions (L*W*H) (mm)

4730*2110*2850

Weight (kg)

7300

Travel Speed (km/h)

0-2.5

Solar pile driving systems are changing the way ground mount solar systems are installed. This crawler hydraulic drilling rig adopts unique construction technology and climbing mechanism design, which can be adjusted according to the slope height, suitable for maximum 45 degrees slope solar engineering construction. This Solar Pile Driver is capable of all kinds of PV constructional technologies: screw pile drilling, spiral hole drilling, rock DTH hammer, ramming pile, and so on. The machine hydraulic parts adopt imported original parts, greatly improving the performance and stability of the equipment; the machine has a compact structure, and the mast has a telescopic compensation function, during working the mast is supported on the ground, so it has high borehole stability. This Solar Pile Driver has reliable performance, high efficiency, and multifunctional applications. This solar piling machine is currently the strongest mountainous solar drilling rig in the Philippines! The drilling rig can also be used for anchoring, water wells, water conservancy, power plant, open-pit mining, roadbuilding, and other blasting hole constructions.
