MHT-X 10180

Key Specs

  • Lifting capacity: 18 000 kg
  • Lifting height: 9.63 m
  • Max reach: 5.56 m
  • Engine: Mercedes – Stage 3A
  • Power: 129 kW
  • Standard Fork: 1200 L x 125 W x 50 T mm
Key Feature

The Manitou Telehandler MHT-X 10180 telehandler has a maximum capacity of 18 tonnes and is perfectly suited to handling incredibly heavy loads. The hydrostatic transmission combined with motorised parts and an impressive tractive force mean this is one powerful–yet flexible–machine that gives you the safety and precision you need for work on a daily basis.

Easily manoeuvrable thanks to 4-wheel drive, 3 steering modes a very generous ground clearance, it can easily get out of even the tightest manoeuvring situations. There’s a wide range of attachments available for this truly versatile machine.

Compare

Description

 :
 :

Lifting height 9.63 m 31’7″
Lifting capacity 18000 kg 39600 lb
Max reach 5.56 m 18’3″
Drawbar pull 15970 dan 35901 lbf
Moving speed 25 kmh 15.5 mph
Lifting time (unladen) 33 s
Lowering time (unladen) 25 s
Boom extension time (unladen) 13.5 s
Boom retraction time (unladen) 13.4 s
Crowd 7 s
Dump 7 s
Length (up to the back of the fork) 6.65 m 21’8″
Total length (fork included) 8.15 m 26’8″
Wheelbase length 3.75 m 12’4″
Width 2.52 m 8’2″
Height 3 m 9’10”
Weight (unladen) 24000 kg 52910.943 lb
Turning radius 5.5 m 18’0″
Ground clearance 0.44 m 1’5″

 :
 :
 :
Energy Diesel
Engine brand Mercedes
Engine type Stage 3A
Engine manufacturer type OM 904 LA. E3A/1
Power 176 ch 176 hp
Power 129 KW
Max. Torque @ Rotation 675 Nm @ 1600 tr/min
Number of cylinders 4
Total capacity 4250 cm3 259.3509 in3
Injection Direct
Cooling Water
Voltage 24 V
Amperage 120 Ah
Transmission type Hydrostatic
Pressure 350 bars
Hydraulic oil tank volume 290 l 76.6 gal
Number of wheels (front/rear) 2/2
Number of drive wheels (front/rear) 2/2
Number of steering wheels (front/rear) 2/2
Number of braking wheels (front/rear) 2/2
Tyre dimensions (front) 16.00-R25
Tyre dimensions (rear) 16.00-R25
Parking brake Automatic negative handbrake
Driving position noise levels 80 dB
Environmental noise levels 107 dB
Vibrations affecting hands/arms <2.5 m/s

Must-have attachments:

Crane Heavy Duty

Heavy Duty Crane

  • 3 forward reach possible for more flexibility in performing daily works
  • Safety: homolologated swivel hook

Heavy Duty Hydraulic Winch

Heavy Duty Hydraulic Winch

  • Oil immersed negative brake for low running costs
  • Double / quadruple (for 12t and above) line pull winch for improved pulling effort
  • Standard cable guide for easy operation
  • Safety: homologated swivel self locking hook

Tyre Handler

Tyre Handler

  • Wide range of tyre handlers to fit to all tyre types
  • Up to 8 combined movements operational as a human wrist
  • Maximum safety: fall prevention arm, 3B6 compliant system

Frame Mounted Hook Heavy Duty

Heavy Duty Frame Mounted Hook

  • Perfect attachment for all heavy suspended-load handlings
  • Very compact attachment that preserves machine’s stability
  • Safety: homologated swivel hook

Cylinder Handler

Cylinder Handler

  • Complete range of cylinder handlers
  • 6 combined movements for more accuracy
  • 2 types of cylinder upholding for more adaptability: clamps (CH 10) or cables (CH 4)


Standard equipment:

  • Batteries 12V – 120AH – 850A (24V)
  • Attachments hooking bar Ø 45 mm
  • Hydraulic line for attachment with fast coupling
  • Battery cut-off
  • Closed Cab with heating and air conditioning
  • Roof Wiper
  • Door with electric window
  • Cloth seat
  • Audio warning in reverse
  • Complete road lighting (front / rear)
  • Reversing light
  • Rotating beacon
  • Inner rear-view mirror
  • Exterior mirrors (left and right)
  • Easy Link Manager Predisposition
  • Load State Monitoring System 3B6
  • System with attachment recognition system (E-reco)
  • Manual towing hitch
  • 16 R25 A2366 AEOLUS Tyres
  • Floating forks carriage on T.S. TFF MT / 1750 + 2 forks 200*80*1200

Optional equipment:

  • Tuner radio
  • CD MP3 car radio
  • CD MP3 Bluetooth car radio
  • Air conditioning (including rear working lights)
  • Windshield protection grid
  • Windshield and roof protection grid
  • Sun visor on the roof and windscreen
  • Document-case
  • Low-frequency pneumatic seat with heating
  • Emergency steering and auxiliary braking
  • Braking system on engine exhaust
  • Rear and lateral camera with cab screen
  • Video cameras (on the top of the boom, right rear side, rear) with cab screen
  • Camera on top of boom
  • Maritime packing
  • R.H. and L.H. front working light (x2)
  • R.H. and L.H. front working lights LED (x2)
  • R.H. and L.H. rear working light (x2)
  • Boom working lights (x2) on fixed part
  • Workings lights on boom head (x2)
  • Working platform predisposition with remote control (suitable also for telescope movements and hydraulic attachments operating) Double battery included MANDATORY to use working platform.
  • Clamp predisposition (including clamp controls from cab)
  • Clamp predisposition including clamp controls from cab (Working platform predisposition with remote control mandatory)
  • Return piping to hydraulic oil tank (Predisposition MANDATORY to use winch, jib with winch or Aerial Jib Platform 1 and 2)
  • Electrovalve 3 hydraulic functions on the top of the boom
  • Attachment hydraulic locking
  • Easy Link Manager Predisposition
  • Special color paints
  • Front foam filled tyres
  • Rims spanner
  • Spare wheel for standard tyres
  • 16 R25 EV-3 GOOD YEAR Tyres
